Description
Product Overview
Keysight positions the RP5923A as a bidirectional regenerative DC power supply for high-power device testing. It is part of the RP5900 Series Regenerative DC Power Supplies. Model-specific evidence confirms output channel: 1, maximum output voltage: 80 V, maximum output/sink current: ±80 A, rated power: 4 kW, and operating quadrant: Two-quadrant source/absorption, supporting engineering work such as automotive and energy system development and automated production power delivery. Exact options, interfaces, accessories, calibration scope, and regional availability depend on the ordered configuration and should be confirmed before purchase.
Key Features
- Output channel: 1.
- Maximum output voltage: 80 V.
- Maximum output/sink current: ±80 A.
- Rated power: 4 kW.
- Operating quadrant: Two-quadrant source/absorption.
- Rack size: 1U.
Technical Specifications
| Output channel | 1 |
|---|---|
| Maximum output voltage | 80 V |
| Maximum output/sink current | ±80 A |
| Rated power | 4 kW |
| operating quadrant | Two-quadrant source/absorption |
| Rack size | 1U |
| AC input | Three-phase 110–520 VAC |
| System interface | LAN/LXI, USB, CAN, digital I/O; other interfaces are confirmed by options |
Typical Applications
- High-power device testing
- Automotive and energy system development
- Automated production power delivery
Selection Notes
The first configuration checks for the Keysight RP5923A are output channel (1) and maximum output voltage (80 V). For a complete selection, verify the voltage, current and power envelope, AC input, regeneration or protection behavior, rack requirements, and system interfaces. Confirm regional availability, calibration scope, included items, and delivery requirements before ordering.
Frequently Asked Questions
What is the Keysight RP5923A?
The Keysight RP5923A is a bidirectional regenerative DC power supply intended for professional test and measurement applications.
What are key specifications of the RP5923A?
Key verified specifications include output channel: 1 and maximum output voltage: 80 V. Review the full table for model-specific details.
How should I specify the Keysight RP5923A for quotation?
State the measurement requirement, selected options, quantity, destination, and calibration or accessory needs. Hoyu Instruments will use those details to confirm the configuration before quoting.
