RIGOL DHO814 Digital Oscilloscope Overview
RIGOL DHO814 is a digital oscilloscope from the DHO800 series. Official RIGOL sources list Vertical resolution 12bits, Analog Bandwidth 100MHz, and Memory Depth 25Mpts pts for this exact model. It is intended for electronic design debugging, signal integrity and waveform analysis, and education, maintenance, and production test. Use the verified specification table below to compare the required configuration, interfaces, probes, modules, and accessories before requesting a quotation.
Key Features
- Verified Vertical resolution: 12bits.
- Verified Analog Bandwidth: 100MHz.
- Verified Memory Depth: 25Mpts pts.
- Verified Waveform Capture Rate: 1,000,000 wfms/s wfms/s.
- Verified Analog Channels: 4.
- Verified Real-time Sample Rate: 1.25GSa/s.
- Verified Input Impedance: 1MΩ.
Technical Specifications
| Vertical resolution | 12bits |
|---|---|
| Analog Bandwidth | 100MHz |
| Memory Depth | 25Mpts pts |
| Waveform Capture Rate | 1,000,000 wfms/s wfms/s |
| Analog Channels | 4 |
| Real-time Sample Rate | 1.25GSa/s |
| Input Impedance | 1MΩ |
Typical Applications
- Electronic design debugging
- Signal integrity and waveform analysis
- Education, maintenance, and production test
Selection Guidance
For the RIGOL DHO814, confirm bandwidth, analog and digital channel count, sample rate, memory depth, probe compatibility, and required protocol or analysis options. Provide the required configuration, quantity, destination country, and application details when requesting a quote.
Frequently Asked Questions
What are the key specifications of the RIGOL DHO814?
The verified record for the RIGOL DHO814 lists Vertical resolution 12bits, Analog Bandwidth 100MHz, and Memory Depth 25Mpts pts. Refer to the complete table on this page because options and measurement conditions may affect the final configuration.
Which applications are suitable for the RIGOL DHO814?
Typical uses include electronic design debugging, signal integrity and waveform analysis, and education, maintenance, and production test. Suitability should be confirmed against the required ranges, channels, interfaces, accessories, and test method.
What information is needed to quote the RIGOL DHO814?
Provide the full model, required options or accessories, quantity, destination country, application, and any calibration or documentation requirements. Hoyu Instruments will confirm configuration and availability before quoting.
