Description
Product Overview
The verified specification set for the Keysight E4980BL covers test frequency: 20 Hz to 300 kHz / 500 kHz / 1 MHz (upgradeable by option), basic accuracy: 0.05% basic impedance accuracy, measurement speed: 12 ms minimum in SHORT mode at 100 kHz to 1 MHz with DC bias off; frequency- and mode-dependent, test signal/offset: 100 µV to 2 Vrms; 1 µA to 20 mA, and measuring range/function: Supports DCR, automatic level control and 201 point list scanning. As an upgradeable precision LCR meter, it is suited to component impedance characterization, with related use in materials and device research and production quality testing. It is part of the E4980B and E4982A Benchtop LCR Meters. Exact options, interfaces, accessories, calibration scope, and regional availability depend on the ordered configuration and should be confirmed before purchase.
Key Features
- Test frequency: 20 Hz to 300 kHz / 500 kHz / 1 MHz (upgradeable by option).
- Basic accuracy: 0.05% basic impedance accuracy.
- Measurement speed: 12 ms minimum in SHORT mode at 100 kHz to 1 MHz with DC bias off; frequency- and mode-dependent.
- Test signal/offset: 100 µV to 2 Vrms; 1 µA to 20 mA.
- Measuring range/function: Supports DCR, automatic level control and 201 point list scanning.
- Communication and system interface: LAN, USB, GPIB.
Technical Specifications
| Test frequency | 20 Hz to 300 kHz / 500 kHz / 1 MHz (upgradeable by option) |
|---|---|
| basic accuracy | 0.05% basic impedance accuracy |
| Measurement speed | 12 ms minimum in SHORT mode at 100 kHz to 1 MHz with DC bias off; frequency- and mode-dependent |
| Test signal/offset | 100 µV to 2 Vrms; 1 µA to 20 mA |
| Measuring range/function | Supports DCR, automatic level control and 201 point list scanning |
| Communication and system interface | LAN, USB, GPIB |
| product status | Current product |
Typical Applications
- Component impedance characterization
- Materials and device research
- Production quality testing
Selection Notes
Evaluate whether the Keysight E4980BL meets the application by comparing test frequency (20 Hz to 300 kHz / 500 kHz / 1 MHz (upgradeable by option)) and basic accuracy (0.05% basic impedance accuracy). In addition, confirm the frequency range, test signal level, measurement accuracy, bias capability, fixture compatibility, and automation interfaces. Confirm regional availability, calibration scope, included items, and delivery requirements before ordering.
Frequently Asked Questions
What is the Keysight E4980BL?
The Keysight E4980BL is an upgradeable precision LCR meter intended for professional test and measurement applications.
What are key specifications of the E4980BL?
Key verified specifications include test frequency: 20 Hz to 300 kHz / 500 kHz / 1 MHz (upgradeable by option) and basic accuracy: 0.05% basic impedance accuracy. Review the full table for model-specific details.
Can Hoyu Instruments quote a configured Keysight E4980BL?
Yes. Supply the required options, interfaces, accessories, calibration scope, quantity, and destination so Hoyu Instruments can prepare a configuration-specific quotation.
