Description
Product Overview
For multi-channel power system integration, the Keysight N6784A combines module type: Four-quadrant source measure unit, output voltage: ±20 V / ±6 V, output current: ±1 A / ±3 A, output power: 20 W, and mainframe slot occupancy: 1 in a four-quadrant source measure unit module platform. It is part of the N6700 Modular Power System. It can also be evaluated for automated device validation and modular laboratory and production testing. Exact options, interfaces, accessories, calibration scope, and regional availability depend on the ordered configuration and should be confirmed before purchase.
Key Features
- Module type: Four-quadrant source measure unit.
- Output voltage: ±20 V / ±6 V.
- Output current: ±1 A / ±3 A.
- Output power: 20 W.
- Mainframe slot occupancy: 1.
- CV ripple vs. noise (rms): 1.2 mV.
Technical Specifications
| module type | Four-quadrant source measure unit |
|---|---|
| Output voltage | ±20 V / ±6 V |
| Output current | ±1 A / ±3 A |
| Output power | 20 W |
| Mainframe slot occupancy | 1 |
| CV ripple vs. noise (rms) | 1.2 mV |
| System interface | GPIB, LAN/LXI, and USB available through the mainframe |
Typical Applications
- Multi-channel power system integration
- Automated device validation
- Modular laboratory and production testing
Selection Notes
Start selection of the Keysight N6784A by checking the verified module type (Four-quadrant source measure unit) and output voltage (±20 V / ±6 V). Then verify mainframe compatibility, module combinations, channel isolation, aggregate power, sequencing, and trigger or control requirements. Confirm regional availability, calibration scope, included items, and delivery requirements before ordering.
Frequently Asked Questions
What is the Keysight N6784A?
The Keysight N6784A is a four-quadrant source measure unit module intended for professional test and measurement applications.
What are key specifications of the N6784A?
Key verified specifications include module type: Four-quadrant source measure unit and output voltage: ±20 V / ±6 V. Review the full table for model-specific details.
What information is needed to quote the N6784A?
Provide the intended application, configuration or options, quantity, delivery country, and any calibration or accessory requirements so the quotation can be checked accurately.
