Description
Product Overview
Keysight positions the EL34243A as a benchtop DC electronic load for power supply and converter testing. It is part of the Keysight Bench Instruments. Model-specific evidence confirms input channel: 2, maximum input voltage: 150 V per input, maximum input current: 60 A per input, maximum absorbed power: 300 W per input, 600 W total, and form factor: Benchtop, supporting engineering work such as battery and energy storage evaluation and automated power test systems. Exact options, interfaces, accessories, calibration scope, and regional availability depend on the ordered configuration and should be confirmed before purchase.
Key Features
- Input channel: 2.
- Maximum input voltage: 150 V per input.
- Maximum input current: 60 A per input.
- Maximum absorbed power: 300 W per input, 600 W total.
- Form factor: Benchtop.
- Load mode: CC, CV, CR, CP, etc..
Technical Specifications
| Input channel | 2 |
|---|---|
| Maximum input voltage | 150 V per input |
| Maximum input current | 60 A per input |
| Maximum absorbed power | 300 W per input, 600 W total |
| Form factor | Benchtop |
| load mode | CC, CV, CR, CP, etc. |
| energy processing | Internal dissipation, no feedback |
Typical Applications
- Power supply and converter testing
- Battery and energy storage evaluation
- Automated power test systems
Selection Notes
The first configuration checks for the Keysight EL34243A are input channel (2) and maximum input voltage (150 V per input). For a complete selection, match the voltage, current and power envelope, operating modes, transient capability, channel configuration, and protection limits. Confirm regional availability, calibration scope, included items, and delivery requirements before ordering.
Frequently Asked Questions
What is the Keysight EL34243A?
The Keysight EL34243A is a benchtop DC electronic load intended for professional test and measurement applications.
What are key specifications of the EL34243A?
Key verified specifications include input channel: 2 and maximum input voltage: 150 V per input. Review the full table for model-specific details.
How should I specify the Keysight EL34243A for quotation?
State the measurement requirement, selected options, quantity, destination, and calibration or accessory needs. Hoyu Instruments will use those details to confirm the configuration before quoting.
