Description
Product Overview
The verified specification set for the Keysight N3304A covers input channel: 1, maximum input voltage: 60 V, maximum input current: 60 A, maximum absorbed power: 300 W, and form factor: plug-in module. As a modular DC electronic load, it is suited to power supply and converter testing, with related use in battery and energy storage evaluation and automated power test systems. It is part of the N3300 Series Modular DC Electronic Loads. Exact options, interfaces, accessories, calibration scope, and regional availability depend on the ordered configuration and should be confirmed before purchase.
Key Features
- Input channel: 1.
- Maximum input voltage: 60 V.
- Maximum input current: 60 A.
- Maximum absorbed power: 300 W.
- Form factor: plug-in module.
- Load mode: CC, CV, CR, CP, etc..
Technical Specifications
| Input channel | 1 |
|---|---|
| Maximum input voltage | 60 V |
| Maximum input current | 60 A |
| Maximum absorbed power | 300 W |
| Form factor | plug-in module |
| load mode | CC, CV, CR, CP, etc. |
| energy processing | Internal dissipation, no feedback |
Typical Applications
- Power supply and converter testing
- Battery and energy storage evaluation
- Automated power test systems
Selection Notes
Evaluate whether the Keysight N3304A meets the application by comparing input channel (1) and maximum input voltage (60 V). In addition, match the voltage, current and power envelope, operating modes, transient capability, channel configuration, and protection limits. Confirm regional availability, calibration scope, included items, and delivery requirements before ordering.
Frequently Asked Questions
What is the Keysight N3304A?
The Keysight N3304A is a modular DC electronic load intended for professional test and measurement applications.
What are key specifications of the N3304A?
Key verified specifications include input channel: 1 and maximum input voltage: 60 V. Review the full table for model-specific details.
Can Hoyu Instruments quote a configured Keysight N3304A?
Yes. Supply the required options, interfaces, accessories, calibration scope, quantity, and destination so Hoyu Instruments can prepare a configuration-specific quotation.
