Description
Product Overview
The verified specification set for the Keysight U1732C covers instrument type: Handheld LCR meter, display resolution: 20,000 counts, capacity range: 20 pF to 20 mF, test frequency: 100 Hz / 120 Hz / 1 kHz / 10 kHz, and basic accuracy: 0.2% + 3 counts. As a handheld LCR meter, it is suited to passive component measurement, with related use in impedance and materials testing and incoming inspection and production QA. It is part of the U1700 Series Handheld Capacitance and LCR Meters. Exact options, interfaces, accessories, calibration scope, and regional availability depend on the ordered configuration and should be confirmed before purchase.
Key Features
- Instrument type: Handheld LCR meter.
- Display resolution: 20,000 counts.
- Capacity range: 20 pF to 20 mF.
- Test frequency: 100 Hz / 120 Hz / 1 kHz / 10 kHz.
- Basic accuracy: 0.2% + 3 counts.
- Model features: Added 10 kHz test and backlight.
Technical Specifications
| Instrument type | Handheld LCR meter |
|---|---|
| display resolution | 20,000 counts |
| Capacity range | 20 pF to 20 mF |
| Test frequency | 100 Hz / 120 Hz / 1 kHz / 10 kHz |
| Basic accuracy | 0.2% + 3 counts |
| Model features | Added 10 kHz test and backlight |
Typical Applications
- Passive component measurement
- Impedance and materials testing
- Incoming inspection and production QA
Selection Notes
Evaluate whether the Keysight U1732C meets the application by comparing instrument type (Handheld LCR meter) and display resolution (20,000 counts). In addition, confirm test frequency, impedance range, accuracy conditions, test signal, fixture compatibility, and handler or automation needs. Confirm regional availability, calibration scope, included items, and delivery requirements before ordering.
Frequently Asked Questions
What is the Keysight U1732C?
The Keysight U1732C is a handheld LCR meter intended for professional test and measurement applications.
What are key specifications of the U1732C?
Key verified specifications include instrument type: Handheld LCR meter and display resolution: 20,000 counts. Review the full table for model-specific details.
Can Hoyu Instruments quote a configured Keysight U1732C?
Yes. Supply the required options, interfaces, accessories, calibration scope, quantity, and destination so Hoyu Instruments can prepare a configuration-specific quotation.
